Belt type Twin Shaft concrete mixer js2000 Welded Type Large capacity 120m3 ready mix batching plant
| Model | HZS90 | HZS120 | HZS150 |
| Discharging Capacity (L) | 1500 | 2000 | 2500 |
| Charging Capacity(L) | 2400 | 3200 | 4000 |
| Maximum Productivity(m³/h) | 90 | 120 | 150 |
| Charging Model | belt conveyor | belt conveyor | belt conveyor |
| Standard Discharging Height(m) | 4.2 | 3.8~4.5 | 4.5 |
| Number of Species of Aggregate | 4 | 4 | 4 |
| Maximum Aggregate Size(mm) | ≤80mm | ≤120mm | ≤150mm |
| Cement/Powder Silo Capacity(set) | 3×100T | 4×100T or 200T | 4×200T |
| Mixing Cycle Time(s) | 60 | 60 | 30 |
| Total Installed Capacity(kw) | 198.06 | 210 | 230 |
Large capacity 120m3 ready mix batching plant is a new generation of concrete mixing equipment developed by China Changli by adopting the international mainstream modular rapid assembly structure and high-performance mixing host. The mixing plant has reasonable structure, advanced design concept, reliable working performance and high mixing efficiency, which can be widely used in road, bridge, water, electricity and other engineering construction and large-scale building construction.
Large capacity 120m3 ready mix batching plant Product advantages
Compared with similar products in the market, Fangtai 120 concrete batching plant has more advantages
1.120 concrete batching plant adopts modular design, and it is very convenient to install and move the whole machine.
2. Good mixing quality and high efficiency.
3. The aggregate is proportioned by batching machine, with accurate measurement and high production efficiency.
4. The batching of cement, water and liquid admixtures are all measured by electronic scale, with high batching accuracy.
5. The water supply system adopts the principle of pump pressurization to speed up the water flow and spray evenly.
6. The main components of electrical control system of Fangtai 120 concrete batching plant are brand products with reliable performance.
7. All material scales shall be measured vertically, with one scale and one meter to improve the measurement accuracy.
8. All the powder materials are in a closed state in the process of transportation, measurement and delivery, so as to avoid dust emission.
Product configuration
Large capacity 120m3 ready mix batching plant Mixing machine
1. Adopt the technology of air pressure sealing protection;
2. The liner adopts special formula, high molybdenum, high chromium and high nickel;
3. The design of multiple mixing knives makes the concrete mixing more uniform;
4. The mixing arm is designed with equal strength and integral casting arm.
Large capacity 120m3 ready mix batching plant Batching machine
1. Coarse and fine weighing to improve weighing accuracy;
2. Microwave humidity measurement system, automatic compensation (user optional);
3. Automatic correction of overshoot and automatic compensation of under balance;
4. Toledo load cell.
Large capacity 120m3 ready mix batching plant Inclined belt conveyor
1. Closed conveying, dustproof and anti dropping;
2. Automatic alarm device for running deviation;
3. Grooved forward tilt idler, self-aligning, to prevent deviation;
4. Falling weight tension, without frequent adjustment;
5. Double side walking platform, convenient for maintenance.
Large capacity 120m3 ready mix batching plant Cement silo
1. Equipped with safety relief protection device;
2. The material level indicating device is set on the top of the bin;
3. Dust removal device is set on the top.
Large capacity 120m3 ready mix batching plant Screw conveyor
1. The blade with variable pitch design has high conveying efficiency;
2. Special design for powder conveying;
3. Maintenance free design of intermediate support.
Large capacity 120m3 ready mix batching plant Weighing device
Toledo sensor ensures the weighing accuracy; Large diameter butterfly valve, high feeding efficiency; Sensor unbalance compensation function.
control room
1. Set up the control room structure;
2. Luxury decoration with air conditioning;
3. Aluminum alloy doors and windows are set around to facilitate observation and operation.
