3-5T/H Dry Mortar Mixing Plant Portable Construction Equipment dry powder mortar mixer
3-5T/H Dry powder mortar mixer of Introduction:
The simple production line is suitable for the production of powder products such as dry mortar and putty powder, etc. The equipment configuration is simple and practical, occupies small space, low investment costs, low maintenance costs, and is ideal for small dry powder product processing plants.Function of raw materials, you can add a batching scale bucket in the production line. If you need to reduce dust in the workplace and improve the working environment of the workers, you can add a small pulse dust collector. In short, we can do different scheme design and configuration according to your requirements.
3-5 t/h dry mortar production line Details:
I. Additionally equipped with secondary screw conveying system, finished product storage silo, automatic packing machine based on multi spiral ribbon mixer, to composed an efficient and reasonable simple dry powder mortar mixer with low cost.
II. Occupation Area 20m2, Height 3.5m, its capacity at 25-30t per day, just on need 2-3 people,very easy to operate.
III. It can realize Automatic Conveying Material, Automatic Mixing, Automatic Filling and Automatic Packing, high efficiency and low cost, which is the priority selection of small and medium dry mortar factory.
Features of simple tile grout making machine
I Small investment and best for individuals.
II Small footprint, ordinary houses can build the factories.
III Easy to operation, 2-3 people can make it.
IV High yield, the output is 3-4T/H usually, to reach 20-25T per day.
V Easy to operation and maintenance.
3-5 t/h dry mortar production line parameter:
| Dry mortar plant | Data | Power |
| Primary feeder | Diameter 165mm, length 3.2m | 3kw |
| Dry mortar mixer | 3.3m*1.05m*2m | 7.5kw |
| Secondary feeder | Diameter 165mm, length 3m | 3kw |
| Hopper | Diameter 1.6m, length 2.8m | / |
| Air compressor | / | 4kw |
| Simple duster | Bag duster | 3kw |
Raw Materials of simple tile grout making machine
I Cementing materials: cement, lime, gypsum.
II Aggregate: yellow sand, quartz sand, limestone, dolomite, expanded perlite, etc.
III Mineral admixture: industrial byproduct, industrial slag, fly ash, pozzolana, fine silica powder, etc.
IV Water-retention and thickening material.
V Chemical additives.
